SpringBoot项目实战

本文最后更新于：1 年前

项目实战-前后端分离博客系统

1.课程介绍

  • 纯后端讲解
  • 完整的前台后台代码编写
  • 主流技术栈（SpringBoot,MybatisPlus,SpringSecurity,EasyExcel,Swagger2,Redis,Echarts,Vue,ElementUI….）
  • 完善细致的需求分析
  • 由易到难循序渐进

2.创建工程

​ 我们有前台和后台两套系统。两套系统的前端工程都已经提供好了。所以我们只需要写两套系统的后端。

​ 但是大家思考下，实际上两套后端系统的很多内容是可能重复的。这里如果我们只是单纯的创建两个后端工程。那么就会有大量的重复代码，并且需要修改的时候也需要修改两次。这就是代码复用性不高。

​ 所以我们需要创建多模块项目，两套系统可能都会用到的代码可以写到一个公共模块中，让前台系统和后台系统分别取依赖公共模块。

① 创建父模块

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.sangeng</groupId>
    <artifactId>SGBlog</artifactId>
    <packaging>pom</packaging>
    <version>1.0-SNAPSHOT</version>
    <modules>
        <module>sangeng-framework</module>
        <module>sangeng-admin</module>
        <module>sangeng-blog</module>
    </modules>

    <properties>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <java.version>1.8</java.version>
    </properties>
    <dependencyManagement>


    <dependencies>
        <!-- SpringBoot的依赖配置-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-dependencies</artifactId>
            <version>2.5.0</version>
            <type>pom</type>
            <scope>import</scope>
        </dependency>
        <!--fastjson依赖-->
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.33</version>
        </dependency>
        <!--jwt依赖-->
        <dependency>
            <groupId>io.jsonwebtoken</groupId>
            <artifactId>jjwt</artifactId>
            <version>0.9.0</version>
        </dependency>
        <!--mybatisPlus依赖-->
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>3.4.3</version>
        </dependency>

        <!--阿里云OSS-->
        <dependency>
            <groupId>com.aliyun.oss</groupId>
            <artifactId>aliyun-sdk-oss</artifactId>
            <version>3.10.2</version>
        </dependency>


        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>easyexcel</artifactId>
            <version>3.0.5</version>
        </dependency>

        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger2</artifactId>
            <version>2.9.2</version>
        </dependency>
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger-ui</artifactId>
            <version>2.9.2</version>
        </dependency>
    </dependencies>


    </dependencyManagement>

    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-compiler-plugin</artifactId>
                <version>3.1</version>
                <configuration>
                    <source>${java.version}</source>
                    <target>${java.version}</target>
                    <encoding>${project.build.sourceEncoding}</encoding>
                </configuration>
            </plugin>
        </plugins>
    </build>
</project>

②创建公共子模块 sangeng-framework

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>SGBlog</artifactId>
        <groupId>com.sangeng</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>

    <artifactId>sangeng-framework</artifactId>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <!--lombk-->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <!--junit-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
        <!--SpringSecurity启动器-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-security</artifactId>
        </dependency>
        <!--redis依赖-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-redis</artifactId>
        </dependency>
        <!--fastjson依赖-->
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
        </dependency>
        <!--jwt依赖-->
        <dependency>
            <groupId>io.jsonwebtoken</groupId>
            <artifactId>jjwt</artifactId>
        </dependency>
        <!--mybatisPlus依赖-->
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
        </dependency>
        <!--mysql数据库驱动-->
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
        </dependency>

        <!--阿里云OSS-->
        <dependency>
            <groupId>com.aliyun.oss</groupId>
            <artifactId>aliyun-sdk-oss</artifactId>
        </dependency>

        <!--AOP-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-aop</artifactId>
        </dependency>

        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>easyexcel</artifactId>
        </dependency>
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger2</artifactId>
        </dependency>
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger-ui</artifactId>
        </dependency>

    </dependencies>
</project>

③创建博客后台模块sangeng-admin

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>SGBlog</artifactId>
        <groupId>com.sangeng</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>

    <artifactId>sangeng-admin</artifactId>

    <dependencies>
        <dependency>
            <groupId>com.sangeng</groupId>
            <artifactId>sangeng-framework</artifactId>
            <version>1.0-SNAPSHOT</version>
        </dependency>
    </dependencies>
</project>

④创建博客前台模块sangeng-blog

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>SGBlog</artifactId>
        <groupId>com.sangeng</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>

    <artifactId>sangeng-blog</artifactId>

    <dependencies>
        <dependency>
            <groupId>com.sangeng</groupId>
            <artifactId>sangeng-framework</artifactId>
            <version>1.0-SNAPSHOT</version>
        </dependency>
    </dependencies>

</project>

3.博客前台

3.0 准备工作

3.1 SpringBoot和MybatisPuls整合配置测试

①创建启动类

1
2
3
4
5
6
7
8
9
10
11
/**
 * @Author 三更  B站： https://space.bilibili.com/663528522
 */
@SpringBootApplication
@MapperScan("com.sangeng.mapper")
public class SanGengBlogApplication {

    public static void main(String[] args) {
        SpringApplication.run(SanGengBlogApplication.class,args);
    }
}

②创建application.yml配置文件

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
server:
  port: 7777
spring:
  datasource:
    url: jdbc:mysql://localhost:3306/sg_blog?characterEncoding=utf-8&serverTimezone=Asia/Shanghai
    username: root
    password: root
    driver-class-name: com.mysql.cj.jdbc.Driver
  servlet:
    multipart:
      max-file-size: 2MB
      max-request-size: 5MB
mybatis-plus:
  configuration:
    # 日志
    log-impl: org.apache.ibatis.logging.stdout.StdOutImpl
  global-config:
    db-config:
      logic-delete-field: delFlag
      logic-delete-value: 1
      logic-not-delete-value: 0
      id-type: auto

③ SQL语句

​ SQL脚本：SGBlog\资源\SQL\sg_article.sql

④ 创建实体类，Mapper，Service

​ 注意思考这些文件应该写在哪个模块下？

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
@SuppressWarnings("serial")
@Data
@AllArgsConstructor
@NoArgsConstructor
@TableName("sg_article")
public class Article  {
    @TableId
    private Long id;
    //标题
    private String title;
    //文章内容
    private String content;
    //文章类型:1 文章 2草稿
    private String type;
    //文章摘要
    private String summary;
    //所属分类id
    private Long categoryId;
    //缩略图
    private String thumbnail;
    //是否置顶（0否，1是）
    private String isTop;
    //状态（0已发布，1草稿）
    private String status;
    //评论数
    private Integer commentCount;
    //访问量
    private Long viewCount;
    //是否允许评论 1是，0否
    private String isComment;

    private Long createBy;

    private Date createTime;

    private Long updateBy;

    private Date updateTime;
    //删除标志（0代表未删除，1代表已删除）
    private Integer delFlag;

}


1
2
3
4
5
public interface ArticleMapper extends BaseMapper<Article> {


}

1
2
3
public interface ArticleService extends IService<Article> {
}

1
2
3
4
@Service
public class ArticleServiceImpl extends ServiceImpl<ArticleMapper, Article> implements ArticleService {

}

⑤ 创建Controller测试接口

​ 注意思考这些文件应该写在哪个模块下？

1
2
3
4
5
6
7
8
9
10
11
12
13
@RestController
@RequestMapping("/article")
public class ArticleController {

    @Autowired
    private ArticleService articleService;

    @GetMapping("/list")
    public List<Article> test(){
        return articleService.list();
    }
}

​ 我们可以暂时先注释掉sangeng-framework中的SpringSecurity依赖方便测试

3.1 热门文章列表

3.1.0 文章表分析

​ 通过需求去分析需要有哪些字段。

3.1.1 需求

​ 需要查询浏览量最高的前10篇文章的信息。要求展示文章标题和浏览量。把能让用户自己点击跳转到具体的文章详情进行浏览。

​ 注意：不能把草稿展示出来，不能把删除了的文章查询出来。要按照浏览量进行降序排序。

3.1.2 接口设计

​ 见接口文档

3.1.3 基础版本代码实现

①准备工作

统一响应类和响应枚举

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
package com.sangeng.domain;

import com.fasterxml.jackson.annotation.JsonInclude;
import com.sangeng.enums.AppHttpCodeEnum;

import java.io.Serializable;

@JsonInclude(JsonInclude.Include.NON_NULL)
public class ResponseResult<T> implements Serializable {
    private Integer code;
    private String msg;
    private T data;

    public ResponseResult() {
        this.code = AppHttpCodeEnum.SUCCESS.getCode();
        this.msg = AppHttpCodeEnum.SUCCESS.getMsg();
    }

    public ResponseResult(Integer code, T data) {
        this.code = code;
        this.data = data;
    }

    public ResponseResult(Integer code, String msg, T data) {
        this.code = code;
        this.msg = msg;
        this.data = data;
    }

    public ResponseResult(Integer code, String msg) {
        this.code = code;
        this.msg = msg;
    }

    public static ResponseResult errorResult(int code, String msg) {
        ResponseResult result = new ResponseResult();
        return result.error(code, msg);
    }
    public static ResponseResult okResult() {
        ResponseResult result = new ResponseResult();
        return result;
    }
    public static ResponseResult okResult(int code, String msg) {
        ResponseResult result = new ResponseResult();
        return result.ok(code, null, msg);
    }

    public static ResponseResult okResult(Object data) {
        ResponseResult result = setAppHttpCodeEnum(AppHttpCodeEnum.SUCCESS, AppHttpCodeEnum.SUCCESS.getMsg());
        if(data!=null) {
            result.setData(data);
        }
        return result;
    }

    public static ResponseResult errorResult(AppHttpCodeEnum enums){
        return setAppHttpCodeEnum(enums,enums.getMsg());
    }

    public static ResponseResult errorResult(AppHttpCodeEnum enums, String msg){
        return setAppHttpCodeEnum(enums,msg);
    }

    public static ResponseResult setAppHttpCodeEnum(AppHttpCodeEnum enums){
        return okResult(enums.getCode(),enums.getMsg());
    }

    private static ResponseResult setAppHttpCodeEnum(AppHttpCodeEnum enums, String msg){
        return okResult(enums.getCode(),msg);
    }

    public ResponseResult<?> error(Integer code, String msg) {
        this.code = code;
        this.msg = msg;
        return this;
    }

    public ResponseResult<?> ok(Integer code, T data) {
        this.code = code;
        this.data = data;
        return this;
    }

    public ResponseResult<?> ok(Integer code, T data, String msg) {
        this.code = code;
        this.data = data;
        this.msg = msg;
        return this;
    }

    public ResponseResult<?> ok(T data) {
        this.data = data;
        return this;
    }

    public Integer getCode() {
        return code;
    }

    public void setCode(Integer code) {
        this.code = code;
    }

    public String getMsg() {
        return msg;
    }

    public void setMsg(String msg) {
        this.msg = msg;
    }

    public T getData() {
        return data;
    }

    public void setData(T data) {
        this.data = data;
    }



}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
package com.sangeng.enums;

public enum AppHttpCodeEnum {
    // 成功
    SUCCESS(200,"操作成功"),
    // 登录
    NEED_LOGIN(401,"需要登录后操作"),
    NO_OPERATOR_AUTH(403,"无权限操作"),
    SYSTEM_ERROR(500,"出现错误"),
    USERNAME_EXIST(501,"用户名已存在"),
     PHONENUMBER_EXIST(502,"手机号已存在"), EMAIL_EXIST(503, "邮箱已存在"),
    REQUIRE_USERNAME(504, "必需填写用户名"),
    LOGIN_ERROR(505,"用户名或密码错误");
    int code;
    String msg;

    AppHttpCodeEnum(int code, String errorMessage){
        this.code = code;
        this.msg = errorMessage;
    }

    public int getCode() {
        return code;
    }

    public String getMsg() {
        return msg;
    }
}

② 代码实现

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
@RestController
@RequestMapping("/article")
public class ArticleController {

    @Autowired
    private ArticleService articleService;

    @GetMapping("/hotArticleList")
    public ResponseResult hotArticleList(){

        ResponseResult result =  articleService.hotArticleList();
        return result;
    }
}

1
2
3
4
public interface ArticleService extends IService<Article> {
    ResponseResult hotArticleList();
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
@Service
public class ArticleServiceImpl extends ServiceImpl<ArticleMapper, Article> implements ArticleService {

    @Override
    public ResponseResult hotArticleList() {
        //查询热门文章 封装成ResponseResult返回
        LambdaQueryWrapper<Article> queryWrapper = new LambdaQueryWrapper<>();
        //必须是正式文章
        queryWrapper.eq(Article::getStatus,0);
        //按照浏览量进行排序
        queryWrapper.orderByDesc(Article::getViewCount);
        //最多只查询10条
        Page<Article> page = new Page(1,10);
        page(page,queryWrapper);

        List<Article> articles = page.getRecords();
        return ResponseResult.okResult(articles);
    }
}

③ 解决跨域问题

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
@Configuration
public class WebConfig implements WebMvcConfigurer {

    @Override
    public void addCorsMappings(CorsRegistry registry) {
      // 设置允许跨域的路径
        registry.addMapping("/**")
                // 设置允许跨域请求的域名
                .allowedOriginPatterns("*")
                // 是否允许cookie
                .allowCredentials(true)
                // 设置允许的请求方式
                .allowedMethods("GET", "POST", "DELETE", "PUT")
                // 设置允许的header属性
                .allowedHeaders("*")
                // 跨域允许时间
                .maxAge(3600);
    }

}

3.1.4 使用VO优化

​ 目前我们的响应格式其实是不符合接口文档的标准的，多返回了很多字段。这是因为我们查询出来的结果是Article来封装的，Article中字段比较多。

​ 我们在项目中一般最后还要把VO来接受查询出来的结果。一个接口对应一个VO，这样即使接口响应字段要修改也只要改VO即可。

1
2
3
4
5
6
7
8
9
10
11
12
@Data
@NoArgsConstructor
@AllArgsConstructor
public class HotArticleVo {
    private Long id;
    //标题
    private String title;

    //访问量
    private Long viewCount;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
@Service
public class ArticleServiceImpl extends ServiceImpl<ArticleMapper, Article> implements ArticleService {

    @Override
    public ResponseResult hotArticleList() {
        //查询热门文章 封装成ResponseResult返回
        LambdaQueryWrapper<Article> queryWrapper = new LambdaQueryWrapper<>();
        //必须是正式文章
        queryWrapper.eq(Article::getStatus,0);
        //按照浏览量进行排序
        queryWrapper.orderByDesc(Article::getViewCount);
        //最多只查询10条
        Page<Article> page = new Page(1,10);
        page(page,queryWrapper);

        List<Article> articles = page.getRecords();
        //bean拷贝
        List<HotArticleVo> articleVos = new ArrayList<>();
        for (Article article : articles) {
            HotArticleVo vo = new HotArticleVo();
            BeanUtils.copyProperties(article,vo);
            articleVos.add(vo);
        }

        return ResponseResult.okResult(articleVos);
    }
}

3.1.5 字面值处理

​ 实际项目中都不允许直接在代码中使用字面值。都需要定义成常量来使用。这种方式有利于提高代码的可维护性。

1
2
3
4
5
6
7
8
9
10
11
12
public class SystemConstants
{
    /**
     *  文章是草稿
     */
    public static final int ARTICLE_STATUS_DRAFT = 1;
    /**
     *  文章是正常分布状态
     */
    public static final int ARTICLE_STATUS_NORMAL = 0;

}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
@Service
public class ArticleServiceImpl extends ServiceImpl<ArticleMapper, Article> implements ArticleService {

    @Override
    public ResponseResult hotArticleList() {
        //查询热门文章 封装成ResponseResult返回
        LambdaQueryWrapper<Article> queryWrapper = new LambdaQueryWrapper<>();
        //必须是正式文章
        queryWrapper.eq(Article::getStatus, SystemConstants.ARTICLE_STATUS_NORMAL);
        //按照浏览量进行排序
        queryWrapper.orderByDesc(Article::getViewCount);
        //最多只查询10条
        Page<Article> page = new Page(1,10);
        page(page,queryWrapper);

        List<Article> articles = page.getRecords();
        //bean拷贝
        List<HotArticleVo> articleVos = new ArrayList<>();
        for (Article article : articles) {
            HotArticleVo vo = new HotArticleVo();
            BeanUtils.copyProperties(article,vo);
            articleVos.add(vo);
        }

        return ResponseResult.okResult(articleVos);
    }
}

3.2 Bean拷贝工具类封装

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
public class BeanCopyUtils {

    private BeanCopyUtils() {
    }

    public static <V> V copyBean(Object source,Class<V> clazz) {
        //创建目标对象
        V result = null;
        try {
            result = clazz.newInstance();
            //实现属性copy
            BeanUtils.copyProperties(source, result);
        } catch (Exception e) {
            e.printStackTrace();
        }
        //返回结果
        return result;
    }
    public static <O,V> List<V> copyBeanList(List<O> list,Class<V> clazz){
        return list.stream()
                .map(o -> copyBean(o, clazz))
                .collect(Collectors.toList());
    }
}

3.2 查询分类列表

3.2.0 分类表分析

​ 通过需求去分析需要有哪些字段。

​ 建表SQL及初始化数据见：SGBlog\资源\SQL\sg_category.sql

3.2.1 需求

image-20220202111056036

​ 页面上需要展示分类列表，用户可以点击具体的分类查看该分类下的文章列表。

​ 注意： ①要求只展示有发布正式文章的分类 ②必须是正常状态的分类

3.2.2 接口设计

​ 见接口文档

3.2.3 EasyCode代码模板

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
##导入宏定义
$!{define.vm}

##保存文件（宏定义）
#save("/entity", ".java")

##包路径（宏定义）
#setPackageSuffix("entity")

##自动导入包（全局变量）
$!{autoImport.vm}

import java.io.Serializable;
import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;
import com.baomidou.mybatisplus.annotation.TableId;
import com.baomidou.mybatisplus.annotation.TableName;
##表注释（宏定义）
#tableComment("表实体类")
@SuppressWarnings("serial")
@Data
@AllArgsConstructor
@NoArgsConstructor
@TableName("$!{tableInfo.obj.name}")
public class $!{tableInfo.name}  {
#foreach($column in $tableInfo.pkColumn)
    #if(${column.comment})//${column.comment}#end
@TableId
    private $!{tool.getClsNameByFullName($column.type)} $!{column.name};
#end

#foreach($column in $tableInfo.otherColumn)
    #if(${column.comment})//${column.comment}#end

    private $!{tool.getClsNameByFullName($column.type)} $!{column.name};
#end



}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
##导入宏定义
$!{define.vm}

##设置表后缀（宏定义）
#setTableSuffix("Mapper")

##保存文件（宏定义）
#save("/mapper", "Mapper.java")

##包路径（宏定义）
#setPackageSuffix("mapper")

import com.baomidou.mybatisplus.core.mapper.BaseMapper;


##表注释（宏定义）
#tableComment("表数据库访问层")
public interface $!{tableName} extends BaseMapper<$!tableInfo.name> {

}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
##导入宏定义
$!{define.vm}

##设置表后缀（宏定义）
#setTableSuffix("Service")

##保存文件（宏定义）
#save("/service", "Service.java")

##包路径（宏定义）
#setPackageSuffix("service")

import com.baomidou.mybatisplus.extension.service.IService;


##表注释（宏定义）
#tableComment("表服务接口")
public interface $!{tableName} extends IService<$!tableInfo.name> {

}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
##导入宏定义
$!{define.vm}

##设置表后缀（宏定义）
#setTableSuffix("ServiceImpl")

##保存文件（宏定义）
#save("/service/impl", "ServiceImpl.java")

##包路径（宏定义）
#setPackageSuffix("service.impl")

import com.baomidou.mybatisplus.extension.service.impl.ServiceImpl;
import org.springframework.stereotype.Service;

##表注释（宏定义）
#tableComment("表服务实现类")
@Service("$!tool.firstLowerCase($tableInfo.name)Service")
public class $!{tableName} extends ServiceImpl<$!{tableInfo.name}Mapper, $!{tableInfo.name}> implements $!{tableInfo.name}Service {

}

3.2.4 代码实现

1
2
3
4
5
6
7
8
9
10
11
12
13
14
@RestController
@RequestMapping("/category")
public class CategoryController {

    @Autowired
    private CategoryService categoryService;

    @GetMapping("/getCategoryList")
    public ResponseResult getCategoryList(){
       return categoryService.getCategoryList();
    }
}


1
2
3
4
5
6
public interface CategoryService extends IService<Category> {


    ResponseResult getCategoryList();

}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
@Service("categoryService")
public class CategoryServiceImpl extends ServiceImpl<CategoryMapper, Category> implements CategoryService {

    @Autowired
    private ArticleService articleService;

    @Override
    public ResponseResult getCategoryList() {
        //查询文章表  状态为已发布的文章
        LambdaQueryWrapper<Article> articleWrapper = new LambdaQueryWrapper<>();
        articleWrapper.eq(Article::getStatus,SystemConstants.ARTICLE_STATUS_NORMAL);
        List<Article> articleList = articleService.list(articleWrapper);
        //获取文章的分类id，并且去重
        Set<Long> categoryIds = articleList.stream()
                .map(article -> article.getCategoryId())
                .collect(Collectors.toSet());

        //查询分类表
        List<Category> categories = listByIds(categoryIds);
        categories = categories.stream().
                filter(category -> SystemConstants.STATUS_NORMAL.equals(category.getStatus()))
                .collect(Collectors.toList());
        //封装vo
        List<CategoryVo> categoryVos = BeanCopyUtils.copyBeanList(categories, CategoryVo.class);

        return ResponseResult.okResult(categoryVos);
    }
}

3.3 分页查询文章列表

3.3.1 需求

​ 在首页和分类页面都需要查询文章列表。

​ 首页：查询所有的文章

​ 分类页面：查询对应分类下的文章

​ 要求：①只能查询正式发布的文章 ②置顶的文章要显示在最前面

3.3.2 接口设计

​ 见文档

3.3.3 代码实现

MP支持分页配置

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
/**
 * @Author 三更  B站： https://space.bilibili.com/663528522
 */
@Configuration
public class MbatisPlusConfig {

    /**
     * 3.4.0之后版本
     * @return
     */
    @Bean
    public MybatisPlusInterceptor mybatisPlusInterceptor(){
        MybatisPlusInterceptor mybatisPlusInterceptor = new MybatisPlusInterceptor();
        mybatisPlusInterceptor.addInnerInterceptor(new PaginationInnerInterceptor());
        return mybatisPlusInterceptor;
    }
}

在ArticleController中

1
2
3
4
@GetMapping("/articleList")
public ResponseResult articleList(Integer pageNum,Integer pageSize,Long categoryId){
    return articleService.articleList(pageNum,pageSize,categoryId);
}

在ArticleService中

1
ResponseResult articleList(Integer pageNum, Integer pageSize, Long categoryId);

在ArticleServiceImpl中

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
@Service
public class ArticleServiceImpl extends ServiceImpl<ArticleMapper, Article> implements ArticleService {

    @Autowired
    private CategoryService categoryService;

    @Override
    public ResponseResult hotArticleList() {
        //查询热门文章 封装成ResponseResult返回
        LambdaQueryWrapper<Article> queryWrapper = new LambdaQueryWrapper<>();
        //必须是正式文章
        queryWrapper.eq(Article::getStatus, SystemConstants.ARTICLE_STATUS_NORMAL);
        //按照浏览量进行排序
        queryWrapper.orderByDesc(Article::getViewCount);
        //最多只查询10条
        Page<Article> page = new Page(1,10);
        page(page,queryWrapper);

        List<Article> articles = page.getRecords();
        //bean拷贝
//        List<HotArticleVo> articleVos = new ArrayList<>();
//        for (Article article : articles) {
//            HotArticleVo vo = new HotArticleVo();
//            BeanUtils.copyProperties(article,vo);
//            articleVos.add(vo);
//        }
        List<HotArticleVo> vs = BeanCopyUtils.copyBeanList(articles, HotArticleVo.class);
        return ResponseResult.okResult(vs);
    }

    @Override
    public ResponseResult articleList(Integer pageNum, Integer pageSize, Long categoryId) {
        //查询条件
        LambdaQueryWrapper<Article> lambdaQueryWrapper = new LambdaQueryWrapper<>();
        // 如果 有categoryId 就要 查询时要和传入的相同
        lambdaQueryWrapper.eq(Objects.nonNull(categoryId)&&categoryId>0 ,Article::getCategoryId,categoryId);
        // 状态是正式发布的
        lambdaQueryWrapper.eq(Article::getStatus,SystemConstants.ARTICLE_STATUS_NORMAL);
        // 对isTop进行降序
        lambdaQueryWrapper.orderByDesc(Article::getIsTop);

        //分页查询
        Page<Article> page = new Page<>(pageNum,pageSize);
        page(page,lambdaQueryWrapper);

        List<Article> articles = page.getRecords();
        //查询categoryName
        articles.stream()
                .map(article -> article.setCategoryName(categoryService.getById(article.getCategoryId()).getName()))
                .collect(Collectors.toList());
        //articleId去查询articleName进行设置
//        for (Article article : articles) {
//            Category category = categoryService.getById(article.getCategoryId());
//            article.setCategoryName(category.getName());
//        }

        //封装查询结果
        List<ArticleListVo> articleListVos = BeanCopyUtils.copyBeanList(page.getRecords(), ArticleListVo.class);

        PageVo pageVo = new PageVo(articleListVos,page.getTotal());
        return ResponseResult.okResult(pageVo);
    }
}

PageVo

1
2
3
4
5
6
7
8
@Data
@NoArgsConstructor
@AllArgsConstructor
public class PageVo {
    private List rows;
    private Long total;
}

ArticleListVo

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
@Data
@NoArgsConstructor
@AllArgsConstructor
public class ArticleListVo {

    private Long id;
    //标题
    private String title;
    //文章摘要
    private String summary;
    //所属分类名
    private String categoryName;
    //缩略图
    private String thumbnail;


    //访问量
    private Long viewCount;

    private Date createTime;


}

在Article中增加一个字段

1
2
@TableField(exist = false)
private String categoryName;

3.3.4 FastJson配置

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
@Bean//使用@Bean注入fastJsonHttpMessageConvert
public HttpMessageConverter fastJsonHttpMessageConverters() {
    //1.需要定义一个Convert转换消息的对象
    FastJsonHttpMessageConverter fastConverter = new FastJsonHttpMessageConverter();
    FastJsonConfig fastJsonConfig = new FastJsonConfig();
    fastJsonConfig.setSerializerFeatures(SerializerFeature.PrettyFormat);
    fastJsonConfig.setDateFormat("yyyy-MM-dd HH:mm:ss");

    SerializeConfig.globalInstance.put(Long.class, ToStringSerializer.instance);

    fastJsonConfig.setSerializeConfig(SerializeConfig.globalInstance);
    fastConverter.setFastJsonConfig(fastJsonConfig);
    HttpMessageConverter<?> converter = fastConverter;
    return converter;
}

@Override
public void configureMessageConverters(List<HttpMessageConverter<?>> converters) {
    converters.add(fastJsonHttpMessageConverters());
}

3.4 文章详情接口

3.4.1 需求

​ 要求在文章列表点击阅读全文时能够跳转到文章详情页面，可以让用户阅读文章正文。

​ 要求：①要在文章详情中展示其分类名

3.4.2 接口设计

请求方式 请求路径
Get /article/{id}

响应格式：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
{
  "code": 200,
  "data": {
    "categoryId": "1",
    "categoryName": "java",
    "content": "内容",
    "createTime": "2022-01-23 23:20:11",
    "id": "1",
    "isComment": "0",
    "title": "SpringSecurity从入门到精通",
    "viewCount": "114"
  },
  "msg": "操作成功"
}

3.4.3 代码实现

ArticleController中新增

1
2
3
4
@GetMapping("/{id}")
public ResponseResult getArticleDetail(@PathVariable("id") Long id){
    return articleService.getArticleDetail(id);
}

Service

1
ResponseResult getArticleDetail(Long id);

ServiceImpl

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
@Override
public ResponseResult getArticleDetail(Long id) {
    //根据id查询文章
    Article article = getById(id);
    //转换成VO
    ArticleDetailVo articleDetailVo = BeanCopyUtils.copyBean(article, ArticleDetailVo.class);
    //根据分类id查询分类名
    Long categoryId = articleDetailVo.getCategoryId();
    Category category = categoryService.getById(categoryId);
    if(category!=null){
        articleDetailVo.setCategoryName(category.getName());
    }
    //封装响应返回
    return ResponseResult.okResult(articleDetailVo);
}

3.5 友联查询

3.5.0 友链表分析

​ 通过需求去分析需要有哪些字段。

​ 建表SQL及初始化数据见：SGBlog\资源\SQL\sg_link.sql

3.5.1 需求

​ 在友链页面要查询出所有的审核通过的友链。

3.5.2 接口设计

请求方式 请求路径
Get /link/getAllLink

响应格式：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
{
  "code": 200,
  "data": [
    {
      "address": "https://www.baidu.com",
      "description": "sda",
      "id": "1",
      "logo": "图片url1",
      "name": "sda"
    },
    {
      "address": "https://www.qq.com",
      "description": "dada",
      "id": "2",
      "logo": "图片url2",
      "name": "sda"
    }
  ],
  "msg": "操作成功"
}

3.5.3 代码实现

Controller

1
2
3
4
5
6
7
8
9
10
11
12
13
@RestController
@RequestMapping("/link")
public class LinkController {

    @Autowired
    private LinkService linkService;

    @GetMapping("/getAllLink")
    public ResponseResult getAllLink(){
        return linkService.getAllLink();
    }
}

Service

1
2
3
4
5
6
public interface LinkService extends IService<Link> {

    ResponseResult getAllLink();
}


ServiceImpl

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
@Service("linkService")
public class LinkServiceImpl extends ServiceImpl<LinkMapper, Link> implements LinkService {

    @Override
    public ResponseResult getAllLink() {
        //查询所有审核通过的
        LambdaQueryWrapper<Link> queryWrapper = new LambdaQueryWrapper<>();
        queryWrapper.eq(Link::getStatus, SystemConstants.LINK_STATUS_NORMAL);
        List<Link> links = list(queryWrapper);
        //转换成vo
        List<LinkVo> linkVos = BeanCopyUtils.copyBeanList(links, LinkVo.class);
        //封装返回
        return ResponseResult.okResult(linkVos);
    }
}

SystemConstants

1
2
3
4
/**
 * 友链状态为审核通过
 */
public static final String  LINK_STATUS_NORMAL = "0";

3.6 登录功能实现

​ 使用我们前台和后台的认证授权统一都使用SpringSecurity安全框架来实现。

3.6.0 需求

​ 需要实现登录功能

​ 有些功能必须登录后才能使用，未登录状态是不能使用的。

3.6.1 接口设计

请求方式 请求路径
POST /login

请求体：

1
2
3
4
{
    "userName":"sg",
    "password":"1234"
}

响应格式：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
{
    "code": 200,
    "data": {
        "token": "eyJhbGciOiJIUzI1NiJ9.eyJqdGkiOiI0ODBmOThmYmJkNmI0NjM0OWUyZjY2NTM0NGNjZWY2NSIsInN1YiI6IjEiLCJpc3MiOiJzZyIsImlhdCI6MTY0Mzg3NDMxNiwiZXhwIjoxNjQzOTYwNzE2fQ.ldLBUvNIxQCGemkCoMgT_0YsjsWndTg5tqfJb77pabk",
        "userInfo": {
            "avatar": "https://gimg2.baidu.com/image_search/src=http%3A%2F%2Fi0.hdslb.com%2Fbfs%2Farticle%2F3bf9c263bc0f2ac5c3a7feb9e218d07475573ec8.gi",
            "email": "23412332@qq.com",
            "id": 1,
            "nickName": "sg333",
            "sex": "1"
        }
    },
    "msg": "操作成功"
}

3.6.2 表分析

​ 建表SQL及初始化数据见：SGBlog\资源\SQL\sys_user.sql

​ 顺便生成下User和UserMapper后面会用到

3.6.3 思路分析

登录

​ ①自定义登录接口

​ 调用ProviderManager的方法进行认证 如果认证通过生成jwt

​ 把用户信息存入redis中

​ ②自定义UserDetailsService

​ 在这个实现类中去查询数据库

​ 注意配置passwordEncoder为BCryptPasswordEncoder

校验：

​ ①定义Jwt认证过滤器

​ 获取token

​ 解析token获取其中的userid

​ 从redis中获取用户信息

​ 存入SecurityContextHolder

3.6.4 准备工作

①添加依赖

注意放开Security依赖的注释

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
<!--redis依赖-->
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-data-redis</artifactId>
</dependency>
<!--fastjson依赖-->
<dependency>
    <groupId>com.alibaba</groupId>
    <artifactId>fastjson</artifactId>
    <version>1.2.33</version>
</dependency>
<!--jwt依赖-->
<dependency>
    <groupId>io.jsonwebtoken</groupId>
    <artifactId>jjwt</artifactId>
    <version>0.9.0</version>
</dependency>

②工具类和相关配置类

​ 见 ：SGBlog\资源\登录功能所需资源

3.6.5 登录接口代码实现

BlogLoginController
1
2
3
4
5
6
7
8
9
10
11
@RestController
public class BlogLoginController {
    @Autowired
    private BlogLoginService blogLoginService;

    @PostMapping("/login")
    public ResponseResult login(@RequestBody User user){
        return blogLoginService.login(user);
    }
}

BlogLoginService
1
2
3
4
public interface BlogLoginService {
    ResponseResult login(User user);
}

SecurityConfig
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
@Configuration
public class SecurityConfig extends WebSecurityConfigurerAdapter {

    @Bean
    public PasswordEncoder passwordEncoder(){
        return new BCryptPasswordEncoder();
    }
    @Override
    protected void configure(HttpSecurity http) throws Exception {
        http
                //关闭csrf
                .csrf().disable()
                //不通过Session获取SecurityContext
                .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS)
                .and()
                .authorizeRequests()
                // 对于登录接口 允许匿名访问
                .antMatchers("/login").anonymous()
                // 除上面外的所有请求全部不需要认证即可访问
                .anyRequest().permitAll();


        http.logout().disable();
        //允许跨域
        http.cors();
    }
    @Override
    @Bean
    public AuthenticationManager authenticationManagerBean() throws Exception {
        return super.authenticationManagerBean();
    }
}
BlogLoginServiceImpl
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
@Service
public class BlogLoginServiceImpl implements BlogLoginService {

    @Autowired
    private AuthenticationManager authenticationManager;

    @Autowired
    private RedisCache redisCache;

    @Override
    public ResponseResult login(User user) {
        UsernamePasswordAuthenticationToken authenticationToken = new UsernamePasswordAuthenticationToken(user.getUserName(),user.getPassword());
        Authentication authenticate = authenticationManager.authenticate(authenticationToken);
        //判断是否认证通过
        if(Objects.isNull(authenticate)){
            throw new RuntimeException("用户名或密码错误");
        }
        //获取userid 生成token
        LoginUser loginUser = (LoginUser) authenticate.getPrincipal();
        String userId = loginUser.getUser().getId().toString();
        String jwt = JwtUtil.createJWT(userId);
        //把用户信息存入redis
        redisCache.setCacheObject("bloglogin:"+userId,loginUser);

        //把token和userinfo封装 返回
        //把User转换成UserInfoVo
        UserInfoVo userInfoVo = BeanCopyUtils.copyBean(loginUser.getUser(), UserInfoVo.class);
        BlogUserLoginVo vo = new BlogUserLoginVo(jwt,userInfoVo);
        return ResponseResult.okResult(vo);
    }
}
UserDetailServiceImpl
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
@Service
public class UserDetailsServiceImpl implements UserDetailsService {

    @Autowired
    private UserMapper userMapper;

    @Override
    public UserDetails loadUserByUsername(String username) throws UsernameNotFoundException {
        //根据用户名查询用户信息
        LambdaQueryWrapper<User> queryWrapper = new LambdaQueryWrapper<>();
        queryWrapper.eq(User::getUserName,username);
        User user = userMapper.selectOne(queryWrapper);
        //判断是否查到用户  如果没查到抛出异常
        if(Objects.isNull(user)){
            throw new RuntimeException("用户不存在");
        }
        //返回用户信息
        // TODO 查询权限信息封装
        return new LoginUser(user);
    }
}
LoginUser
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
@Data
@AllArgsConstructor
@NoArgsConstructor
public class LoginUser implements UserDetails {

    private User user;


    @Override
    public Collection<? extends GrantedAuthority> getAuthorities() {
        return null;
    }

    @Override
    public String getPassword() {
        return user.getPassword();
    }

    @Override
    public String getUsername() {
        return user.getUserName();
    }

    @Override
    public boolean isAccountNonExpired() {
        return true;
    }

    @Override
    public boolean isAccountNonLocked() {
        return true;
    }

    @Override
    public boolean isCredentialsNonExpired() {
        return true;
    }

    @Override
    public boolean isEnabled() {
        return true;
    }
}

BlogUserLoginVo
1
2
3
4
5
6
7
8
@Data
@NoArgsConstructor
@AllArgsConstructor
public class BlogUserLoginVo {

    private String token;
    private UserInfoVo userInfo;
}
UserInfoVo
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
@Data
@Accessors(chain = true)
public class UserInfoVo {
    /**
     * 主键
     */
    private Long id;

    /**
     * 昵称
     */
    private String nickName;

    /**
     * 头像
     */
    private String avatar;

    private String sex;

    private String email;


}

3.6.6 登录校验过滤器代码实现

思路

​ ①定义Jwt认证过滤器

​ 获取token

​ 解析token获取其中的userid

​ 从redis中获取用户信息

​ 存入SecurityContextHolder

JwtAuthenticationTokenFilter
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
@Component
public class JwtAuthenticationTokenFilter extends OncePerRequestFilter {

    @Autowired
    private RedisCache redisCache;

    @Override
    protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response, FilterChain filterChain) throws ServletException, IOException {
        //获取请求头中的token
        String token = request.getHeader("token");
        if(!StringUtils.hasText(token)){
            //说明该接口不需要登录  直接放行
            filterChain.doFilter(request, response);
            return;
        }
        //解析获取userid
        Claims claims = null;
        try {
            claims = JwtUtil.parseJWT(token);
        } catch (Exception e) {
            e.printStackTrace();
            //token超时  token非法
            //响应告诉前端需要重新登录
            ResponseResult result = ResponseResult.errorResult(AppHttpCodeEnum.NEED_LOGIN);
            WebUtils.renderString(response, JSON.toJSONString(result));
            return;
        }
        String userId = claims.getSubject();
        //从redis中获取用户信息
        LoginUser loginUser = redisCache.getCacheObject("bloglogin:" + userId);
        //如果获取不到
        if(Objects.isNull(loginUser)){
            //说明登录过期  提示重新登录
            ResponseResult result = ResponseResult.errorResult(AppHttpCodeEnum.NEED_LOGIN);
            WebUtils.renderString(response, JSON.toJSONString(result));
            return;
        }
        //存入SecurityContextHolder
        UsernamePasswordAuthenticationToken authenticationToken = new UsernamePasswordAuthenticationToken(loginUser,null,null);
        SecurityContextHolder.getContext().setAuthentication(authenticationToken);

        filterChain.doFilter(request, response);
    }


}
SecurityConfig
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
@Configuration
public class SecurityConfig extends WebSecurityConfigurerAdapter {

    @Override
    @Bean
    public AuthenticationManager authenticationManagerBean() throws Exception {
        return super.authenticationManagerBean();
    }

    @Autowired
    private JwtAuthenticationTokenFilter jwtAuthenticationTokenFilter;

    @Override
    protected void configure(HttpSecurity http) throws Exception {
        http
                //关闭csrf
                .csrf().disable()
                //不通过Session获取SecurityContext
                .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS)
                .and()
                .authorizeRequests()
                // 对于登录接口 允许匿名访问
                .antMatchers("/login").anonymous()
                //jwt过滤器测试用，如果测试没有问题吧这里删除了
                .antMatchers("/link/getAllLink").authenticated()
                // 除上面外的所有请求全部不需要认证即可访问
                .anyRequest().permitAll();


        http.logout().disable();
        //把jwtAuthenticationTokenFilter添加到SpringSecurity的过滤器链中
        http.addFilterBefore(jwtAuthenticationTokenFilter, UsernamePasswordAuthenticationFilter.class);
        //允许跨域
        http.cors();
    }

    @Bean
    public PasswordEncoder passwordEncoder(){
        return new BCryptPasswordEncoder();
    }
}

3.7 认证授权失败处理

​ 目前我们的项目在认证出错或者权限不足的时候响应回来的Json是Security的异常处理结果。但是这个响应的格式肯定是不符合我们项目的接口规范的。所以需要自定义异常处理。

​ AuthenticationEntryPoint 认证失败处理器

​ AccessDeniedHandler 授权失败处理器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
@Component
public class AuthenticationEntryPointImpl implements AuthenticationEntryPoint {

    @Override
    public void commence(HttpServletRequest request, HttpServletResponse response, AuthenticationException authException) throws IOException, ServletException {
        authException.printStackTrace();
        //InsufficientAuthenticationException
        //BadCredentialsException
        ResponseResult result = null;
        if(authException instanceof BadCredentialsException){
            result = ResponseResult.errorResult(AppHttpCodeEnum.LOGIN_ERROR.getCode(),authException.getMessage());
        }else if(authException instanceof InsufficientAuthenticationException){
            result = ResponseResult.errorResult(AppHttpCodeEnum.NEED_LOGIN);
        }else{
            result = ResponseResult.errorResult(AppHttpCodeEnum.SYSTEM_ERROR.getCode(),"认证或授权失败");
        }
        //响应给前端
        WebUtils.renderString(response, JSON.toJSONString(result));
    }
}

1
2
3
4
5
6
7
8
9
10
11
@Component
public class AccessDeniedHandlerImpl implements AccessDeniedHandler {
    @Override
    public void handle(HttpServletRequest request, HttpServletResponse response, AccessDeniedException accessDeniedException) throws IOException, ServletException {
        accessDeniedException.printStackTrace();
        ResponseResult result = ResponseResult.errorResult(AppHttpCodeEnum.NO_OPERATOR_AUTH);
        //响应给前端
        WebUtils.renderString(response, JSON.toJSONString(result));
    }
}

配置Security异常处理器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
@Configuration
public class SecurityConfig extends WebSecurityConfigurerAdapter {

    @Override
    @Bean
    public AuthenticationManager authenticationManagerBean() throws Exception {
        return super.authenticationManagerBean();
    }

    @Autowired
    private JwtAuthenticationTokenFilter jwtAuthenticationTokenFilter;
    @Autowired
    AuthenticationEntryPoint authenticationEntryPoint;
    @Autowired
    AccessDeniedHandler accessDeniedHandler;


    @Override
    protected void configure(HttpSecurity http) throws Exception {
        http
                //关闭csrf
                .csrf().disable()
                //不通过Session获取SecurityContext
                .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS)
                .and()
                .authorizeRequests()
                // 对于登录接口 允许匿名访问
                .antMatchers("/login").anonymous()
                //jwt过滤器测试用，如果测试没有问题吧这里删除了
                .antMatchers("/link/getAllLink").authenticated()
                // 除上面外的所有请求全部不需要认证即可访问
                .anyRequest().permitAll();

        //配置异常处理器
        http.exceptionHandling()
                .authenticationEntryPoint(authenticationEntryPoint)
                .accessDeniedHandler(accessDeniedHandler);

        http.logout().disable();
        //把jwtAuthenticationTokenFilter添加到SpringSecurity的过滤器链中
        http.addFilterBefore(jwtAuthenticationTokenFilter, UsernamePasswordAuthenticationFilter.class);
        //允许跨域
        http.cors();
    }

    @Bean
    public PasswordEncoder passwordEncoder(){
        return new BCryptPasswordEncoder();
    }
}

3.8 统一异常处理

​ 实际我们在开发过程中可能需要做很多的判断校验，如果出现了非法情况我们是期望响应对应的提示的。但是如果我们每次都自己手动去处理就会非常麻烦。我们可以选择直接抛出异常的方式，然后对异常进行统一处理。把异常中的信息封装成ResponseResult响应给前端。

​

SystemException

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
/**
 * @Author 三更  B站： https://space.bilibili.com/663528522
 */
public class SystemException extends RuntimeException{

    private int code;

    private String msg;

    public int getCode() {
        return code;
    }

    public String getMsg() {
        return msg;
    }

    public SystemException(AppHttpCodeEnum httpCodeEnum) {
        super(httpCodeEnum.getMsg());
        this.code = httpCodeEnum.getCode();
        this.msg = httpCodeEnum.getMsg();
    }

}

GlobalExceptionHandler

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
@RestControllerAdvice
@Slf4j
public class GlobalExceptionHandler {

    @ExceptionHandler(SystemException.class)
    public ResponseResult systemExceptionHandler(SystemException e){
        //打印异常信息
        log.error("出现了异常！ {}",e);
        //从异常对象中获取提示信息封装返回
        return ResponseResult.errorResult(e.getCode(),e.getMsg());
    }


    @ExceptionHandler(Exception.class)
    public ResponseResult exceptionHandler(Exception e){
        //打印异常信息
        log.error("出现了异常！ {}",e);
        //从异常对象中获取提示信息封装返回
        return ResponseResult.errorResult(AppHttpCodeEnum.SYSTEM_ERROR.getCode(),e.getMessage());
    }
}

3.9 退出登录接口

3.9.1 接口设计

请求方式 请求地址 请求头
POST /logout 需要token请求头

响应格式:

1
2
3
4
{
    "code": 200,
    "msg": "操作成功"
}

3.9.2 代码实现

要实现的操作：

​ 删除redis中的用户信息

BlogLoginController

1
2
3
4
@PostMapping("/logout")
public ResponseResult logout(){
    return blogLoginService.logout();
}

BlogLoginService

1
ResponseResult logout();

BlogLoginServiceImpl

1
2
3
4
5
6
7
8
9
10
11
@Override
public ResponseResult logout() {
    //获取token 解析获取userid
    Authentication authentication = SecurityContextHolder.getContext().getAuthentication();
    LoginUser loginUser = (LoginUser) authentication.getPrincipal();
    //获取userid
    Long userId = loginUser.getUser().getId();
    //删除redis中的用户信息
    redisCache.deleteObject("bloglogin:"+userId);
    return ResponseResult.okResult();
}

SecurityConfig

要关闭默认的退出登录功能。并且要配置我们的退出登录接口需要认证才能访问

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
  @Override
  protected void configure(HttpSecurity http) throws Exception {
      http
              //关闭csrf
              .csrf().disable()
              //不通过Session获取SecurityContext
              .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS)
              .and()
              .authorizeRequests()
              // 对于登录接口 允许匿名访问
              .antMatchers("/login").anonymous()
          	//注销接口需要认证才能访问
              .antMatchers("/logout").authenticated()
              //jwt过滤器测试用，如果测试没有问题吧这里删除了
              .antMatchers("/link/getAllLink").authenticated()
              // 除上面外的所有请求全部不需要认证即可访问
              .anyRequest().permitAll();

      //配置异常处理器
      http.exceptionHandling()
              .authenticationEntryPoint(authenticationEntryPoint)
              .accessDeniedHandler(accessDeniedHandler);
//关闭默认的注销功能
      http.logout().disable();
      //把jwtAuthenticationTokenFilter添加到SpringSecurity的过滤器链中
      http.addFilterBefore(jwtAuthenticationTokenFilter, UsernamePasswordAuthenticationFilter.class);
      //允许跨域
      http.cors();
  }

3.10 查询评论列表接口

3.10.1 需求

​ 文章详情页面要展示这篇文章下的评论列表。

​ 效果如下:

image-20220208214106296

3.10.2 评论表分析

​ 通过需求去分析需要有哪些字段。

​ 建表SQL及初始化数据见：SGBlog\资源\SQL\sg_comment.sql

​ 顺便生成下对应的代码

3.10.3 接口设计

请求方式 请求地址 请求头
GET /comment/commentList 不需要token请求头

Query格式请求参数：

articleId:文章id

pageNum: 页码

pageSize: 每页条数

响应格式:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
{
    "code": 200,
    "data": {
        "rows": [
            {
                "articleId": "1",
                "children": [
                    {
                        "articleId": "1",
                        "content": "你说啥？",
                        "createBy": "1",
                        "createTime": "2022-01-30 10:06:21",
                        "id": "20",
                        "rootId": "1",
                        "toCommentId": "1",
                        "toCommentUserId": "1",
                        "toCommentUserName": "sg333",
                        "username": "sg333"
                    }
                ],
                "content": "asS",
                "createBy": "1",
                "createTime": "2022-01-29 07:59:22",
                "id": "1",
                "rootId": "-1",
                "toCommentId": "-1",
                "toCommentUserId": "-1",
                "username": "sg333"
            }
        ],
        "total": "15"
    },
    "msg": "操作成功"
}

3.10.4 代码实现

3.10.4.1 不考虑子评论

CommentController

1
2
3
4
5
6
7
8
9
10
11
12
13
@RestController
@RequestMapping("/comment")
public class CommentController {

    @Autowired
    private CommentService commentService;

    @GetMapping("/commentList")
    public ResponseResult commentList(Long articleId,Integer pageNum,Integer pageSize){
        return commentService.commentList(articleId,pageNum,pageSize);
    }
}

CommentService

1
2
3
4
5
public interface CommentService extends IService<Comment> {

    ResponseResult commentList(Long articleId, Integer pageNum, Integer pageSize);
}

CommentServiceImpl

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
@Service("commentService")
public class CommentServiceImpl extends ServiceImpl<CommentMapper, Comment> implements CommentService {

    @Autowired
    private UserService userService;

    @Override
    public ResponseResult commentList(Long articleId, Integer pageNum, Integer pageSize) {
        //查询对应文章的根评论
        LambdaQueryWrapper<Comment> queryWrapper = new LambdaQueryWrapper<>();
        //对articleId进行判断
        queryWrapper.eq(Comment::getArticleId,articleId);
        //根评论 rootId为-1
        queryWrapper.eq(Comment::getRootId,-1);

        //分页查询
        Page<Comment> page = new Page(pageNum,pageSize);
        page(page,queryWrapper);

        List<CommentVo> commentVoList = toCommentVoList(page.getRecords());

        return ResponseResult.okResult(new PageVo(commentVoList,page.getTotal()));
    }

    private List<CommentVo> toCommentVoList(List<Comment> list){
        List<CommentVo> commentVos = BeanCopyUtils.copyBeanList(list, CommentVo.class);
        //遍历vo集合
        for (CommentVo commentVo : commentVos) {
            //通过creatyBy查询用户的昵称并赋值
            String nickName = userService.getById(commentVo.getCreateBy()).getNickName();
            commentVo.setUsername(nickName);
            //通过toCommentUserId查询用户的昵称并赋值
            //如果toCommentUserId不为-1才进行查询
            if(commentVo.getToCommentUserId()!=-1){
                String toCommentUserName = userService.getById(commentVo.getToCommentUserId()).getNickName();
                commentVo.setToCommentUserName(toCommentUserName);
            }
        }
        return commentVos;
    }
}


CommentVo

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
@Data
@NoArgsConstructor
@AllArgsConstructor
public class CommentVo {
    private Long id;
    //文章id
    private Long articleId;
    //根评论id
    private Long rootId;
    //评论内容
    private String content;
    //所回复的目标评论的userid
    private Long toCommentUserId;
    private String toCommentUserName;
    //回复目标评论id
    private Long toCommentId;

    private Long createBy;

    private Date createTime;

    private String username;
}

3.10.4.2 查询子评论

CommentVo在之前的基础上增加了 private List children;

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
@Data
@NoArgsConstructor
@AllArgsConstructor
public class CommentVo {
    private Long id;
    //文章id
    private Long articleId;
    //根评论id
    private Long rootId;
    //评论内容
    private String content;
    //所回复的目标评论的userid
    private Long toCommentUserId;
    private String toCommentUserName;
    //回复目标评论id
    private Long toCommentId;

    private Long createBy;

    private Date createTime;

    private String username;

    private List<CommentVo> children;
}

CommentServiceImpl

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
@Service("commentService")
public class CommentServiceImpl extends ServiceImpl<CommentMapper, Comment> implements CommentService {

    @Autowired
    private UserService userService;

    @Override
    public ResponseResult commentList(Long articleId, Integer pageNum, Integer pageSize) {
        //查询对应文章的根评论
        LambdaQueryWrapper<Comment> queryWrapper = new LambdaQueryWrapper<>();
        //对articleId进行判断
        queryWrapper.eq(Comment::getArticleId,articleId);
        //根评论 rootId为-1
        queryWrapper.eq(Comment::getRootId,-1);

        //分页查询
        Page<Comment> page = new Page(pageNum,pageSize);
        page(page,queryWrapper);

        List<CommentVo> commentVoList = toCommentVoList(page.getRecords());

        //查询所有根评论对应的子评论集合，并且赋值给对应的属性
        for (CommentVo commentVo : commentVoList) {
            //查询对应的子评论
            List<CommentVo> children = getChildren(commentVo.getId());
            //赋值
            commentVo.setChildren(children);
        }

        return ResponseResult.okResult(new PageVo(commentVoList,page.getTotal()));
    }

    /**
     * 根据根评论的id查询所对应的子评论的集合
     * @param id 根评论的id
     * @return
     */
    private List<CommentVo> getChildren(Long id) {

        LambdaQueryWrapper<Comment> queryWrapper = new LambdaQueryWrapper<>();
        queryWrapper.eq(Comment::getRootId,id);
        queryWrapper.orderByAsc(Comment::getCreateTime);
        List<Comment> comments = list(queryWrapper);

        List<CommentVo> commentVos = toCommentVoList(comments);
        return commentVos;
    }

    private List<CommentVo> toCommentVoList(List<Comment> list){
        List<CommentVo> commentVos = BeanCopyUtils.copyBeanList(list, CommentVo.class);
        //遍历vo集合
        for (CommentVo commentVo : commentVos) {
            //通过creatyBy查询用户的昵称并赋值
            String nickName = userService.getById(commentVo.getCreateBy()).getNickName();
            commentVo.setUsername(nickName);
            //通过toCommentUserId查询用户的昵称并赋值
            //如果toCommentUserId不为-1才进行查询
            if(commentVo.getToCommentUserId()!=-1){
                String toCommentUserName = userService.getById(commentVo.getToCommentUserId()).getNickName();
                commentVo.setToCommentUserName(toCommentUserName);
            }
        }
        return commentVos;
    }
}

3.11 发表评论接口

3.11.1 需求

​ 用户登录后可以对文章发表评论，也可以对评论进行回复。

​ 用户登录后也可以在友链页面进行评论。

3.11.2 接口设计

请求方式 请求地址 请求头
POST /comment 需要token头
请求体：

回复了文章：

1
{"articleId":1,"type":0,"rootId":-1,"toCommentId":-1,"toCommentUserId":-1,"content":"评论了文章"}

回复了某条评论：

1
{"articleId":1,"type":0,"rootId":"3","toCommentId":"3","toCommentUserId":"1","content":"回复了某条评论"}

如果是友链评论，type应该为1

响应格式：
1
2
3
4
{
	"code":200,
	"msg":"操作成功"
}

3.11.3 代码实现

CommentController

1
2
3
4
@PostMapping
public ResponseResult addComment(@RequestBody Comment comment){
    return commentService.addComment(comment);
}

CommentService

1
ResponseResult addComment(Comment comment);

CommentServiceImpl

1
2
3
4
5
6
7
8
9
@Override
public ResponseResult addComment(Comment comment) {
    //评论内容不能为空
    if(!StringUtils.hasText(comment.getContent())){
        throw new SystemException(AppHttpCodeEnum.CONTENT_NOT_NULL);
    }
    save(comment);
    return ResponseResult.okResult();
}

SecurityUtils

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
/**
 * @Author 三更  B站： https://space.bilibili.com/663528522
 */
public class SecurityUtils
{

    /**
     * 获取用户
     **/
    public static LoginUser getLoginUser()
    {
        return (LoginUser) getAuthentication().getPrincipal();
    }

    /**
     * 获取Authentication
     */
    public static Authentication getAuthentication() {
        return SecurityContextHolder.getContext().getAuthentication();
    }

    public static Boolean isAdmin(){
        Long id = getLoginUser().getUser().getId();
        return id != null && 1L == id;
    }

    public static Long getUserId() {
        return getLoginUser().getUser().getId();
    }
}

配置MP字段自动填充

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
@Component
public class MyMetaObjectHandler implements MetaObjectHandler {
    @Override
    public void insertFill(MetaObject metaObject) {
        Long userId = null;
        try {
            userId = SecurityUtils.getUserId();
        } catch (Exception e) {
            e.printStackTrace();
            userId = -1L;//表示是自己创建
        }
        this.setFieldValByName("createTime", new Date(), metaObject);
        this.setFieldValByName("createBy",userId , metaObject);
        this.setFieldValByName("updateTime", new Date(), metaObject);
        this.setFieldValByName("updateBy", userId, metaObject);
    }

    @Override
    public void updateFill(MetaObject metaObject) {
        this.setFieldValByName("updateTime", new Date(), metaObject);
        this.setFieldValByName(" ", SecurityUtils.getUserId(), metaObject);
    }
}

用注解标识哪些字段在什么情况下需要自动填充

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
/**
 * 创建人的用户id
 */
@TableField(fill = FieldFill.INSERT)
private Long createBy;
/**
 * 创建时间
 */
@TableField(fill = FieldFill.INSERT)
private Date createTime;
/**
 * 更新人
 */
@TableField(fill = FieldFill.INSERT_UPDATE)
private Long updateBy;
/**
 * 更新时间
 */
@TableField(fill = FieldFill.INSERT_UPDATE)
private Date updateTime;

3.12 友联评论列表

3.12.1 需求

​ 友链页面也需要查询对应的评论列表。

3.12.2 接口设计

请求方式 请求地址 请求头
GET /comment/linkCommentList 不需要token请求头

Query格式请求参数：

pageNum: 页码

pageSize: 每页条数

响应格式:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
{
    "code": 200,
    "data": {
        "rows": [
            {
                "articleId": "1",
                "children": [
                    {
                        "articleId": "1",
                        "content": "回复友链评论3",
                        "createBy": "1",
                        "createTime": "2022-01-30 10:08:50",
                        "id": "23",
                        "rootId": "22",
                        "toCommentId": "22",
                        "toCommentUserId": "1",
                        "toCommentUserName": "sg333",
                        "username": "sg333"
                    }
                ],
                "content": "友链评论2",
                "createBy": "1",
                "createTime": "2022-01-30 10:08:28",
                "id": "22",
                "rootId": "-1",
                "toCommentId": "-1",
                "toCommentUserId": "-1",
                "username": "sg333"
            }
        ],
        "total": "1"
    },
    "msg": "操作成功"
}

3.12.3 代码实现

CommentController 修改了之前的文章评论列表接口，并且增加了新的友联评论接口

1
2
3
4
5
6
7
8
@GetMapping("/commentList")
public ResponseResult commentList(Long articleId,Integer pageNum,Integer pageSize){
    return commentService.commentList(SystemConstants.ARTICLE_COMMENT,articleId,pageNum,pageSize);
}
@GetMapping("/linkCommentList")
public ResponseResult linkCommentList(Integer pageNum,Integer pageSize){
    return commentService.commentList(SystemConstants.LINK_COMMENT,null,pageNum,pageSize);
}

SystemConstants增加了两个常量

1
2
3
4
5
6
7
8
/**
 * 评论类型为：文章评论
 */
public static final String ARTICLE_COMMENT = "0";
/**
 * 评论类型为：友联评论
 */
public static final String LINK_COMMENT = "1";

CommentService修改了commentList方法，增加了一个参数commentType

1
ResponseResult commentList(String commentType, Long articleId, Integer pageNum, Integer pageSize);

CommentServiceImpl修改commentList方法的代码，必须commentType为0的时候才增加articleId的判断，并且增加了一个评论类型的添加。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
@Override
public ResponseResult commentList(String commentType, Long articleId, Integer pageNum, Integer pageSize) {
    //查询对应文章的根评论
    LambdaQueryWrapper<Comment> queryWrapper = new LambdaQueryWrapper<>();
    //对articleId进行判断
    queryWrapper.eq(SystemConstants.ARTICLE_COMMENT.equals(commentType),Comment::getArticleId,articleId);
    //根评论 rootId为-1
    queryWrapper.eq(Comment::getRootId,-1);

    //评论类型
    queryWrapper.eq(Comment::getType,commentType);

    //分页查询
    Page<Comment> page = new Page(pageNum,pageSize);
    page(page,queryWrapper);

    List<CommentVo> commentVoList = toCommentVoList(page.getRecords());

    //查询所有根评论对应的子评论集合，并且赋值给对应的属性
    for (CommentVo commentVo : commentVoList) {
        //查询对应的子评论
        List<CommentVo> children = getChildren(commentVo.getId());
        //赋值
        commentVo.setChildren(children);
    }

    return ResponseResult.okResult(new PageVo(commentVoList,page.getTotal()));
}

3.13 个人信息查询接口

3.13.1 需求

​ 进入个人中心的时候需要能够查看当前用户信息

3.13.2 接口设计

请求方式 请求地址 请求头
GET /user/userInfo 需要token请求头

不需要参数

响应格式:

1
2
3
4
5
6
7
8
9
10
11
{
	"code":200,
	"data":{
		"avatar":"https://gimg2.baidu.com/image_search/src=http%3A%2F%2Fi0.hdslb.com%2Fbfs%2Farticle%2F3bf9c263bc0f2ac5c3a7feb9e218d07475573ec8.gi",
		"email":"23412332@qq.com",
		"id":"1",
		"nickName":"sg333",
		"sex":"1"
	},
	"msg":"操作成功"
}

3.13.3 代码实现

UserController

1
2
3
4
5
6
7
8
9
10
11
12
13
@RestController
@RequestMapping("/user")
public class UserController {

    @Autowired
    private UserService userService;

    @GetMapping("/userInfo")
    public ResponseResult userInfo(){
        return userService.userInfo();
    }
}

UserService增加方法定义

1
2
3
4
5
6
public interface UserService extends IService<User> {

    ResponseResult userInfo();

}

UserServiceImpl实现userInfo方法

1
2
3
4
5
6
7
8
9
10
@Override
public ResponseResult userInfo() {
    //获取当前用户id
    Long userId = SecurityUtils.getUserId();
    //根据用户id查询用户信息
    User user = getById(userId);
    //封装成UserInfoVo
    UserInfoVo vo = BeanCopyUtils.copyBean(user,UserInfoVo.class);
    return ResponseResult.okResult(vo);
}

SecurityConfig配置该接口必须认证后才能访问

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
@Override
 protected void configure(HttpSecurity http) throws Exception {
     http
             //关闭csrf
             .csrf().disable()
             //不通过Session获取SecurityContext
             .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS)
             .and()
             .authorizeRequests()
             // 对于登录接口 允许匿名访问
             .antMatchers("/login").anonymous()
             //注销接口需要认证才能访问
             .antMatchers("/logout").authenticated()
         	//个人信息接口必须登录后才能访问
             .antMatchers("/user/userInfo").authenticated()
             // 除上面外的所有请求全部不需要认证即可访问
             .anyRequest().permitAll();

     //配置异常处理器
     http.exceptionHandling()
             .authenticationEntryPoint(authenticationEntryPoint)
             .accessDeniedHandler(accessDeniedHandler);
     //关闭默认的注销功能
     http.logout().disable();
     //把jwtAuthenticationTokenFilter添加到SpringSecurity的过滤器链中
     http.addFilterBefore(jwtAuthenticationTokenFilter, UsernamePasswordAuthenticationFilter.class);
     //允许跨域
     http.cors();
 }

3.14 头像上传接口

3.14.1 需求

​ 在个人中心点击编辑的时候可以上传头像图片。上传完头像后，可以用于更新个人信息接口。

3.14.2 OSS

3.14.2.1 为什么要使用OSS

​ 因为如果把图片视频等文件上传到自己的应用的Web服务器，在读取图片的时候会占用比较多的资源。影响应用服务器的性能。

​ 所以我们一般使用OSS(Object Storage Service对象存储服务)存储图片或视频。

3.14.2.2 七牛云基本使用测试

image-20220227224537701

image-20220227224443813

秘钥

image-20220228230512598

image-20220228230933808

3.14.2.3 七牛云测试代码编写

①添加依赖

1
2
3
4
5
<dependency>
    <groupId>com.qiniu</groupId>
    <artifactId>qiniu-java-sdk</artifactId>
    <version>[7.7.0, 7.7.99]</version>
</dependency>

②复制修改案例代码

application.yml

1
2
3
4
oss:
  accessKey: 1ltxb75nnwzFNIok8MHVI2RcZzgUJDn3qxCSSzgM
  secretKey: XN4T97vXwUAEUz7LXITWHf3wy6FBHF8pMMtYhwXj
  bucket: sg-blog

OSSTest.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
@SpringBootTest
@ConfigurationProperties(prefix = "oss")
public class OSSTest {

    private String accessKey;
    private String secretKey;
    private String bucket;

    public void setAccessKey(String accessKey) {
        this.accessKey = accessKey;
    }

    public void setSecretKey(String secretKey) {
        this.secretKey = secretKey;
    }

    public void setBucket(String bucket) {
        this.bucket = bucket;
    }

    @Test
    public void testOss(){
        //构造一个带指定 Region 对象的配置类
        Configuration cfg = new Configuration(Region.autoRegion());
        //...其他参数参考类注释

        UploadManager uploadManager = new UploadManager(cfg);
        //...生成上传凭证，然后准备上传
//        String accessKey = "your access key";
//        String secretKey = "your secret key";
//        String bucket = "sg-blog";

        //默认不指定key的情况下，以文件内容的hash值作为文件名
        String key = "2022/sg.png";

        try {
//            byte[] uploadBytes = "hello qiniu cloud".getBytes("utf-8");
//            ByteArrayInputStream byteInputStream=new ByteArrayInputStream(uploadBytes);


            InputStream inputStream = new FileInputStream("C:\\Users\\root\\Desktop\\Snipaste_2022-02-28_22-48-37.png");
            Auth auth = Auth.create(accessKey, secretKey);
            String upToken = auth.uploadToken(bucket);

            try {
                Response response = uploadManager.put(inputStream,key,upToken,null, null);
                //解析上传成功的结果
                DefaultPutRet putRet = new Gson().fromJson(response.bodyString(), DefaultPutRet.class);
                System.out.println(putRet.key);
                System.out.println(putRet.hash);
            } catch (QiniuException ex) {
                Response r = ex.response;
                System.err.println(r.toString());
                try {
                    System.err.println(r.bodyString());
                } catch (QiniuException ex2) {
                    //ignore
                }
            }
        } catch (Exception ex) {
            //ignore
        }

    }
}

3.14.2 接口设计

请求方式 请求地址 请求头
POST /upload 需要token

参数：

​ img,值为要上传的文件

请求头：

​ Content-Type ：multipart/form-data;

响应格式:

1
2
3
4
5
{
    "code": 200,
    "data": "文件访问链接",
    "msg": "操作成功"
}

3.14.3 代码实现

1
2
3
4
5
6
7
8
9
10
11
@RestController
public class UploadController {
    @Autowired
    private UploadService uploadService;

    @PostMapping("/upload")
    public ResponseResult uploadImg(MultipartFile img){
        return uploadService.uploadImg(img);
    }
}

1
2
3
4
public interface UploadService {
    ResponseResult uploadImg(MultipartFile img);
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
@Service
@Data
@ConfigurationProperties(prefix = "oss")
public class OssUploadService implements UploadService {
    @Override
    public ResponseResult uploadImg(MultipartFile img) {
        //判断文件类型
        //获取原始文件名
        String originalFilename = img.getOriginalFilename();
        //对原始文件名进行判断
        if(!originalFilename.endsWith(".png")){
            throw new SystemException(AppHttpCodeEnum.FILE_TYPE_ERROR);
        }

        //如果判断通过上传文件到OSS
        String filePath = PathUtils.generateFilePath(originalFilename);
        String url = uploadOss(img,filePath);//  2099/2/3/wqeqeqe.png
        return ResponseResult.okResult(url);
    }

    private String accessKey;
    private String secretKey;
    private String bucket;


    private String uploadOss(MultipartFile imgFile, String filePath){
        //构造一个带指定 Region 对象的配置类
        Configuration cfg = new Configuration(Region.autoRegion());
        //...其他参数参考类注释
        UploadManager uploadManager = new UploadManager(cfg);
        //默认不指定key的情况下，以文件内容的hash值作为文件名
        String key = filePath;
        try {
            InputStream inputStream = imgFile.getInputStream();
            Auth auth = Auth.create(accessKey, secretKey);
            String upToken = auth.uploadToken(bucket);
            try {
                Response response = uploadManager.put(inputStream,key,upToken,null, null);
                //解析上传成功的结果
                DefaultPutRet putRet = new Gson().fromJson(response.bodyString(), DefaultPutRet.class);
                System.out.println(putRet.key);
                System.out.println(putRet.hash);
                return "http://r7yxkqloa.bkt.clouddn.com/"+key;
            } catch (QiniuException ex) {
                Response r = ex.response;
                System.err.println(r.toString());
                try {
                    System.err.println(r.bodyString());
                } catch (QiniuException ex2) {
                    //ignore
                }
            }
        } catch (Exception ex) {
            //ignore
        }
        return "www";
    }
}

PathUtils

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
/**
 * @Author 三更  B站： https://space.bilibili.com/663528522
 */
public class PathUtils {

    public static String generateFilePath(String fileName){
        //根据日期生成路径   2022/1/15/
        SimpleDateFormat sdf = new SimpleDateFormat("yyyy/MM/dd/");
        String datePath = sdf.format(new Date());
        //uuid作为文件名
        String uuid = UUID.randomUUID().toString().replaceAll("-", "");
        //后缀和文件后缀一致
        int index = fileName.lastIndexOf(".");
        // test.jpg -> .jpg
        String fileType = fileName.substring(index);
        return new StringBuilder().append(datePath).append(uuid).append(fileType).toString();
    }
}

3.15 更新个人信息接口

3.15.1 需求

​ 在编辑完个人资料后点击保存会对个人资料进行更新。

3.15.2 接口设计

​

请求方式 请求地址 请求头
PUT /user/userInfo 需要token请求头

参数

请求体中json格式数据：

1
2
3
4
5
6
7
{
    "avatar":"https://sg-blog-oss.oss-cn-beijing.aliyuncs.com/2022/01/31/948597e164614902ab1662ba8452e106.png",
    "email":"23412332@qq.com",
    "id":"1",
    "nickName":"sg333",
    "sex":"1"
}

响应格式:

1
2
3
4
{
	"code":200,
	"msg":"操作成功"
}

3.15.3 代码实现

UserController

1
2
3
4
@PutMapping("/userInfo")
public ResponseResult updateUserInfo(@RequestBody User user){
    return userService.updateUserInfo(user);
}

UserService

1
ResponseResult updateUserInfo(User user);

UserServiceImpl

1
2
3
4
5
@Override
public ResponseResult updateUserInfo(User user) {
    updateById(user);
    return ResponseResult.okResult();
}

3.16 用户注册

3.16.1 需求

​ 要求用户能够在注册界面完成用户的注册。要求用户名，昵称，邮箱不能和数据库中原有的数据重复。如果某项重复了注册失败并且要有对应的提示。并且要求用户名，密码，昵称，邮箱都不能为空。

​ 注意:密码必须密文存储到数据库中。

3.16.2 接口设计

​

请求方式 请求地址 请求头
POST /user/register 不需要token请求头

参数

请求体中json格式数据：

1
2
3
4
5
6
{
  "email": "string",
  "nickName": "string",
  "password": "string",
  "userName": "string"
}

响应格式:

1
2
3
4
{
	"code":200,
	"msg":"操作成功"
}

3.16.3 代码实现

UserController

1
2
3
4
@PostMapping("/register")
public ResponseResult register(@RequestBody User user){
    return userService.register(user);
}

UserService

1
ResponseResult register(User user);

UserServiceImpl

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
@Autowired
private PasswordEncoder passwordEncoder;
@Override
public ResponseResult register(User user) {
    //对数据进行非空判断
    if(!StringUtils.hasText(user.getUserName())){
        throw new SystemException(AppHttpCodeEnum.USERNAME_NOT_NULL);
    }
    if(!StringUtils.hasText(user.getPassword())){
        throw new SystemException(AppHttpCodeEnum.PASSWORD_NOT_NULL);
    }
    if(!StringUtils.hasText(user.getEmail())){
        throw new SystemException(AppHttpCodeEnum.EMAIL_NOT_NULL);
    }
    if(!StringUtils.hasText(user.getNickName())){
        throw new SystemException(AppHttpCodeEnum.NICKNAME_NOT_NULL);
    }
    //对数据进行是否存在的判断
    if(userNameExist(user.getUserName())){
        throw new SystemException(AppHttpCodeEnum.USERNAME_EXIST);
    }
    if(nickNameExist(user.getNickName())){
        throw new SystemException(AppHttpCodeEnum.NICKNAME_EXIST);
    }
    //...
    //对密码进行加密
    String encodePassword = passwordEncoder.encode(user.getPassword());
    user.setPassword(encodePassword);
    //存入数据库
    save(user);
    return ResponseResult.okResult();
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
public enum AppHttpCodeEnum {
    // 成功
    SUCCESS(200,"操作成功"),
    // 登录
    NEED_LOGIN(401,"需要登录后操作"),
    NO_OPERATOR_AUTH(403,"无权限操作"),
    SYSTEM_ERROR(500,"出现错误"),
    USERNAME_EXIST(501,"用户名已存在"),
     PHONENUMBER_EXIST(502,"手机号已存在"), EMAIL_EXIST(503, "邮箱已存在"),
    REQUIRE_USERNAME(504, "必需填写用户名"),
    CONTENT_NOT_NULL(506, "评论内容不能为空"),
    FILE_TYPE_ERROR(507, "文件类型错误，请上传png文件"),
    USERNAME_NOT_NULL(508, "用户名不能为空"),
    NICKNAME_NOT_NULL(509, "昵称不能为空"),
    PASSWORD_NOT_NULL(510, "密码不能为空"),
    EMAIL_NOT_NULL(511, "邮箱不能为空"),
    NICKNAME_EXIST(512, "昵称已存在"),
    LOGIN_ERROR(505,"用户名或密码错误");
    int code;
    String msg;

    AppHttpCodeEnum(int code, String errorMessage){
        this.code = code;
        this.msg = errorMessage;
    }

    public int getCode() {
        return code;
    }

    public String getMsg() {
        return msg;
    }
}

3.17 AOP实现日志记录

3.17.1 需求

​ 需要通过日志记录接口调用信息。便于后期调试排查。并且可能有很多接口都需要进行日志的记录。

​ 接口被调用时日志打印格式如下：

image-20220313133714102

3.17.2 思路分析

​ 相当于是对原有的功能进行增强。并且是批量的增强，这个时候就非常适合用AOP来进行实现。

​

3.17.3 代码实现

日志打印格式

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
log.info("=======Start=======");
// 打印请求 URL
log.info("URL            : {}",);
// 打印描述信息
log.info("BusinessName   : {}", );
// 打印 Http method
log.info("HTTP Method    : {}", );
// 打印调用 controller 的全路径以及执行方法
log.info("Class Method   : {}.{}", );
// 打印请求的 IP
log.info("IP             : {}",);
// 打印请求入参
log.info("Request Args   : {}",);
// 打印出参
log.info("Response       : {}", );
// 结束后换行
log.info("=======End=======" + System.lineSeparator());

3.18 更新浏览次数

4. Swagger2使用

SpringBoot框架
#java #SpringBoot
SpringBoot项目实战
http://example.com/2021/12/12/SpringBoot项目实战/
作者
Crush
发布于
2021年12月12日
更新于
2023年7月9日
许可协议
